Drawing in 2D

A first picture takes a handful of plain functions, such as background, circle, rect, line and text. Everything else 2D is drawn on the preview's canvas through ctx, its own drawing surface. This page starts with those, then lists what ctx can do, grouped by job, with a short program for each group that you can paste into a Python file and run.

The basics

• Positions are in points, measured from the top-left corner. x grows to the right and y grows down. The bottom-right corner is (width, height).
• Drawing is sharp on every screen: the preview takes care of high-resolution displays for you.
• Say angles in degrees with degrees(). Wherever an angle is wanted, write degrees(90) for a quarter turn or degrees(360) for a full one. The canvas itself counts angles in radians, where a full turn is math.tau (about 6.283); degrees() does the sum for you, so you never need to. Examples you find elsewhere, and the later parts of this page, write angles in radians.
• Colours are text: a name ("red", "skyblue"), a hex code ("#ff8800"), "rgb(255, 136, 0)", "rgba(255, 136, 0, 0.5)" (the last number is opacity, 0 to 1), or "hsl(30, 100%, 50%)" (hue in degrees, then saturation and lightness).
• Two spellings, one call. Every name works in snake_case or in its standard form: ctx.fill_rect(...) is ctx.fillRect(...), and ctx.fill_style is ctx.fillStyle. This guide uses snake_case from here on.
• The preview's background is white in the light theme and near-black in the dark theme. Paint your own background first so your drawing looks the same in both.

The quick way: plain functions

A handful of functions draw the things a first picture needs, one call each. They need no ctx. in front.

def draw():
    background("lightskyblue")
    rect(0, height - 80, width, 80, "yellowgreen")
    circle(width - 80, 80, 45, "gold")
    line(40, height - 80, 40, height - 200, "saddlebrown", 8)
    circle(40, height - 220, 50, "forestgreen")
    text("A tree in the sun", width / 2, 40, "white", 28, "centre")

The rules are the same for all of them:

• The colour can be left out. The shape then uses the colour already in use: the last one you gave, or the one set with ctx.fill_style = "red". A preview starts with black, so give a colour the first time.
• What you give stays. A colour, a thickness, a text's size and "centre" all stay for the shapes drawn after, until you give another. background is the exception: it paints and leaves the colour as it was.
• Shapes are filled unless you ask for an outline, which is next.
• Your own names win. If your program has its own function or variable called circle, text, star or any of the others, yours is used.
• They are for 2D. In a 3D scene they stop with an error that says so.
• There is one picture for everything. A moon, a heart, a rocket: any emoji is a picture, so there is no function for each thing. A file's picture is loaded the first time it is asked for, and appears once it has arrived. An image from load_image can be given too.

Outlines and rounded corners

Every shape takes two more things by name: outline="white", thickness=6. With a colour, the shape is filled and has a border. Without a colour, only the edge is drawn.

def draw():
    background("midnightblue")
    circle(90, 90, 50, "gold", outline="white", thickness=6)       # filled, with a border
    circle(220, 90, 50, outline="white", thickness=6)              # the edge alone
    star(350, 90, 55, 5, "gold")
    rect(40, 180, 160, 80, "tomato", round=20)                     # rounded corners
    polygon(280, 220, 50, 6, outline="lightgreen", thickness=4)    # six sides
    triangle(340, 270, 380, 180, 420, 270, "orchid")
    ellipse(220, 300, 300, 30, "steelblue")
    picture("🌙", 440, 60, 50)

The outline's colour and thickness stay for the next outline, as a fill colour does. rect also takes round, the size of its rounded corners, and star takes inner, how far out its inner corners are as a part of its radius (0.4 unless you say): star(100, 100, 50, 5, "gold", inner=0.6).

Chance: random and pick

random is also the name of a module that comes with Python, and most Python books begin import random. Both work together here: after import random, random(1, 6) still gives a whole number, and random.randint(1, 6) and the rest of the module are there too.

def draw():
    background("black")
    for i in range(50):
        circle(random(width), random(height), random(5, 20), pick(["red", "gold", "white"]))

The long way: ctx

Each of the plain functions is a short way of writing what ctx does. circle(200, 150, 80, "gold") is these four lines:

ctx.fill_style = "gold"
ctx.begin_path()
ctx.arc(200, 150, 80, 0, degrees(360))
ctx.fill()

A circle the long way is an arc that goes all the way round, from angle 0 to a full turn. Half of one is ctx.arc(200, 150, 80, 0, degrees(180)): part circles stay with ctx. ctx is the web's own 2D drawing surface, and it can do far more than they can: curves, any shape you can describe, gradients, shadows, clipping and transforms. The two mix freely in one program. The rest of this page is ctx.

Rectangles

def draw():
    ctx.fill_style = "white"
    ctx.fill_rect(0, 0, width, height)

    ctx.fill_style = "steelblue"
    ctx.fill_rect(40, 40, 160, 100)

    ctx.stroke_style = "crimson"
    ctx.line_width = 6
    ctx.stroke_rect(240, 40, 160, 100)

Tap to enlarge

Paths: lines, circles and any shape

A path is a shape you build from pieces, then fill or outline. Start with begin_path(), add pieces, then call fill() or stroke() (or both).

import math

def draw():
    ctx.fill_style = "#f4f1ea"
    ctx.fill_rect(0, 0, width, height)

    # a circle
    ctx.fill_style = "orange"
    ctx.begin_path()
    ctx.arc(100, 100, 50, 0, math.tau)
    ctx.fill()

    # a triangle, filled and outlined
    ctx.begin_path()
    ctx.move_to(200, 150)
    ctx.line_to(260, 50)
    ctx.line_to(320, 150)
    ctx.close_path()
    ctx.fill_style = "mediumseagreen"
    ctx.fill()
    ctx.stroke_style = "darkgreen"
    ctx.line_width = 4
    ctx.stroke()

    # a wave
    ctx.begin_path()
    ctx.move_to(20, 220)
    ctx.bezier_curve_to(120, 140, 220, 300, 340, 220)
    ctx.stroke_style = "royalblue"
    ctx.stroke()

    # a rounded button
    ctx.begin_path()
    ctx.round_rect(360, 60, 140, 60, 16)
    ctx.fill_style = "teal"
    ctx.fill()

Tap to enlarge

Colours, gradients, lines and transparency

Every way to write a colour, including hsl explained step by step, is on the Colours page.

A gradient is made once, given colour stops from 0 to 1, then used as a style:

import math

sky = ctx.create_linear_gradient(0, 0, 0, 400)
sky.add_color_stop(0, "#1e3c72")
sky.add_color_stop(1, "#f7b267")

glow = ctx.create_radial_gradient(300, 120, 5, 300, 120, 60)
glow.add_color_stop(0, "white")
glow.add_color_stop(1, "rgba(255, 220, 120, 0)")

def draw():
    ctx.fill_style = sky
    ctx.fill_rect(0, 0, width, height)

    ctx.fill_style = glow
    ctx.fill_rect(220, 40, 160, 160)

    # see-through circles
    ctx.global_alpha = 0.6
    for i, colour in enumerate(["red", "lime", "blue"]):
        ctx.fill_style = colour
        ctx.begin_path()
        ctx.arc(100 + i * 40, 260, 50, 0, math.tau)
        ctx.fill()
    ctx.global_alpha = 1

    # a dashed, round-ended line
    ctx.stroke_style = "white"
    ctx.line_width = 6
    ctx.line_cap = "round"
    ctx.set_line_dash([12, 14])
    ctx.begin_path()
    ctx.move_to(20, 360)
    ctx.line_to(width - 20, 360)
    ctx.stroke()
    ctx.set_line_dash([])

Tap to enlarge

Text and fonts: drawing text on the canvas

Emoji are text too, so ctx.fill_text("🚀", x, y) draws a rocket.

def draw():
    ctx.fill_style = "#202833"
    ctx.fill_rect(0, 0, width, height)

    ctx.fill_style = "white"
    ctx.font = "bold 40px sans-serif"
    ctx.text_align = "center"
    ctx.text_baseline = "middle"
    ctx.fill_text("Centred title", width / 2, 60)

    ctx.font = "20px monospace"
    ctx.text_align = "left"
    ctx.fill_style = "#9fe"
    for i, line in enumerate(["first line", "second line", "third line"]):
        ctx.fill_text(line, 30, 130 + i * 30)

    ctx.font = "64px sans-serif"
    ctx.fill_text("🌈 ⭐ 🚀", 30, 260)

    ctx.font = "bold 48px serif"
    ctx.stroke_style = "gold"
    ctx.line_width = 2
    ctx.stroke_text("Outline", 30, 340)

Tap to enlarge

Moving, turning and scaling: transforms

A transform moves the whole drawing grid, so the shapes after it are drawn in the moved grid. It is the easy way to rotate something around its own centre.

Always pair save() with restore(), so one shape's transform does not leak into the next.

import math

angle = 0

def update(dt):
    global angle
    angle += dt

def draw():
    ctx.fill_style = "white"
    ctx.fill_rect(0, 0, width, height)
    for i in range(5):
        ctx.save()
        ctx.translate(80 + i * 110, height / 2)   # move to the square's centre
        ctx.rotate(angle * (i + 1) / 2)          # spin around it
        ctx.scale(1 + i * 0.2, 1 + i * 0.2)
        ctx.fill_style = f"hsl({i * 60}, 70%, 50%)"
        ctx.fill_rect(-20, -20, 40, 40)          # drawn around (0, 0)
        ctx.restore()

Tap to enlarge

Pictures

load_image(address) loads a picture from a web address or a data: address and gives you an image to draw. It draws once it has finished loading, so draw it in draw() and it appears as soon as it is ready. In Circuitry a picture from a website is asked about first (what a program can reach).

This picture is made in Python as a small SVG drawing, so it needs no internet:

from urllib.parse import quote

svg = """<svg xmlns='http://www.w3.org/2000/svg' width='64' height='64'>
<circle cx='32' cy='32' r='30' fill='gold'/>
<circle cx='22' cy='26' r='5' fill='black'/>
<circle cx='42' cy='26' r='5' fill='black'/>
<path d='M18 40 Q32 54 46 40' stroke='black' stroke-width='4' fill='none'/>
</svg>"""

def draw():
    ctx.fill_style = "#cde"
    ctx.fill_rect(0, 0, width, height)
    ctx.draw_image(smiley, 20, 20)
    ctx.draw_image(smiley, 120, 20, 160, 160)

Tap to enlarge

Sprites

A Sprite is a picture that moves. The picture can be an emoji or any short text, an image from load_image, or a function that draws it. It draws itself centred on its x, y.

rocket = Sprite("🚀", x=100, y=200, size=64)

import math, random

fish = [Sprite("🐟", random.uniform(0, 400), random.uniform(40, 300), size=40) for _ in range(6)]
for f in fish:
    f.vx = random.uniform(40, 120)
shark = Sprite("🦈", 0, 200, size=72)
shark.vx = 60

def update(dt):
    for f in fish + [shark]:
        f.update(dt)
        f.wrap()
    for f in fish:
        f.visible = not f.touches(shark)
    shark.angle = math.sin(shark.x / 40) * 0.2

def draw():
    ctx.fill_style = "#0b4f6c"
    ctx.fill_rect(0, 0, width, height)
    for f in fish:
        f.draw()
    shark.draw()

Sprites that touch

hit is the one a game uses most: one thing against many.

rock = bullet.hit(rocks)
if rock:
    remove(rocks, rock)
    score += 10

sprite.touches(other) is a question you ask a sprite. The list called touches is a different thing: every finger that is down, which you loop over.

A sprite is tested as a circle or as a box. It is a circle unless you say otherwise.

What is exact, and what is not:

• Circle against circle, box against box and circle against box are all exact for the shapes above.
• A box that is turned (its angle is not 0) is tested properly against a circle and against a point. Two boxes are tested as if neither were turned.
• The shape is a circle or a box, never the outline of the picture. A long thin picture wants a box.
• Two shapes that only just meet at their edges do not touch. A sprite of size 0 touches nothing.
• A hidden sprite still touches. That is useful for a goal you cannot see. To stop a sprite touching, take it out of its list.

Leaving the picture, and moving the way it faces

Call wrap() or bounce() after update(dt), every frame. With these there is no trigonometry to write: a ship that turns, flies and faces the mouse is

ship.spin = 4 if "ArrowRight" in keys else 0
if "ArrowUp" in keys:
    ship.push(300 * dt)
if mouse.down:
    ship.angle = ship.angle_to(mouse)
ship.update(dt)
ship.wrap()

Pictures you draw yourself

Give a sprite a function in place of a picture and it is called to draw the sprite. It is given the sprite's size. Draw round 0, 0, which is the sprite's centre, and facing right: the sprite puts it in place and turns it.

def arrow(size):
    triangle(size / 2, 0, -size / 2, -size / 3, -size / 2, size / 3, "gold")

pointer = Sprite(arrow, 200, 150, size=60)

def update(dt):
    pointer.angle = pointer.angle_to(mouse)

def draw():
    ctx.fill_style = "#123"
    ctx.fill_rect(0, 0, width, height)
    pointer.draw()

To draw with ctx itself, write the function as def arrow(ctx, size): and it is given ctx as well.

Two plain shapes are ready made. Each is hit-tested as exactly the shape you see.

The colour is white unless you say, and can be changed later: ball.colour = "red" (color works too).

ball = Sprite.circle(200, 100, 20, "orange")
bat = Sprite.box(200, 260, 100, 14)
ball.vx = 150
ball.vy = 200

def update(dt):
    bat.x = mouse.x
    ball.update(dt)
    ball.bounce()
    if ball.vy > 0 and ball.touches(bat):
        ball.vy = -ball.vy

def draw():
    ctx.fill_style = "#123"
    ctx.fill_rect(0, 0, width, height)
    ball.draw()
    bat.draw()

Taking things out of a list

Games remove things all the time: a bullet that has left the picture, a rock that was hit. remove(things, thing) takes one thing out of a list (and does nothing if it is not there, where Python's own things.remove(thing) would stop with an error).

Removing from a list while a loop is going through that same list makes the loop skip things. So loop over a copy, written things[:], and remove from the real one:

for bullet in bullets[:]:
    bullet.update(dt)
    if bullet.offscreen():
        remove(bullets, bullet)

Use this one way everywhere and it is never wrong.

The simple game tutorial builds a game from emoji sprites, and the Space Rocks tutorial builds one from sprites you draw. The examples space_rocks.py, bat_and_ball.py and brick_breaker.py are whole games made this way.

Everything else

ctx is the standard 2D drawing surface, so any other operation it has works the same way, in either spelling: clipping (ctx.clip()), pixel access (ctx.get_image_data, ctx.put_image_data), filters (ctx.filter = "blur(4px)") and the rest. Reading pixels back is a read, so it needs await and is slow; drawing is not. 2D functions lists every one, grouped, with pictures.
